2006 Joulin Aero Automatic assembly plant Joulin Aero P21N

Automatic Assembly and acceptance system Joulin Aero Lifting capacity: Pack of boards Max. 2 X 4000 mm 1200 mm 1500 mm 18 mm 1800 mm Board Min. L= 4000mm W= 100mm, T= 18mm Bord Max.L= 4000mm W= 250mm, T=100mm Wood density : maxi 700 Kg / m3 lifting capacity approx.. 800 KG According their Specification: 2 packages = 2 x ( 4 x1,5 x 0,10 m ) = 1,2 m3 x 840 Kg ( wood density m3) Handling of aluminium plate 8200 mm long or wood specific indications : Packs of boards always centred under the machine Offer: JOULIN Stacker type 1000 TS 18.000.- Euro Control system + electro cabinet 10.500.- Euro system check and proof 2.500.- Euro Total cost all in all: 31.000 EURO
