SCM 2041 FS Planer and Thicknesser
Description
SCM 2041 FS Planer and Thicknesser
Manufacturer SCM Italy
AB 66989
Ref 110830
Year of manufacture approx. 1994, from school use in good condition
3 cutterblock
Planing shaft speed 5000 rpm
Planing:
Table length 2000 mm
Planing width 410 mm
Support table length 1040 mm
Support table length 910 mm
Max. Chip thickness: 10 mm
Jointing fence swivelling 0 - 45°
Table adjustment for planer with rotary lever
Pressure link vibration guard
Thickness planing:
Planing width 410 mm
Max. chip thickness: 7.5 mm Chip thickness: 7.5 mm
Min. planer thickness: 3 mm
Max. planer thickness: 240 mm Planing thickness: 240 mm
Thicknessing table length: 730 mm
Sliding table roller
Planing shaft speed 5000 rpm
Feed speeds 6 and 10 m/min
Height adjustment of thicknessing table with handwheel
Infeed roller steel
Exit roller steel
Connections:
Motor power: 4 kW with motor brake
Voltage: 400 V
Frequency: 50 Hz
Fuse protection: 16 A
Machine dimensions
Length 2000 mm
Width 1450 mm
Height 1100 mm
Weight 800 kg
Specifications
| Manufacturer | SCM Italy |
| Model | FS 2041 |
| Year | 1994 |
| Condition | Used |
| Stock Number | M_1162 |
